New Symbols
Radar Chart+
This update introduces an entirely new custom symbol, the Radar Chart+. Radar Chart+ is a highly configurable custom symbol for AVEVA PI Vision that visualizes multiple process values across units or assets using a polar (spider) chart. Ideal for comparing equipment performance or highlighting anomalies.
New Features
General
- All symbols now support french and turkish language
- PI Vision Timezone override is now supported by the symbols
All Tables
- The excel data export now properly sets the multi state colors and cell types
- Additional styling options for the PDF export
Events Table+
- Changes to how the Edit Mode works: In this mode, data for pi points will only be displayed if there's an actual data point with the event frames time range - otherwise the cell will be empty, indicating no value for that event
- The table will now correctly use the initial search configuration
- General performance improvements
Manual Input Table+
- Header Filters now support numbers and datetime data types
- New Options for handling duplicate time stamps: Replace, Insert or Ignore
- For pasting and importing, a new "Skip Time Column" has been introduced, where only data is imported and the time string is generated by the table itself
- New timestamps for added rows: Display Start- and Endtime
Manual Data Entry+
- New Options for handling duplicate time stamps: Replace, Insert or Ignore
- Custom column headers
Histogram+
- The histogram will now use server-side calculations: Improved performance, loading time and no limits on the amount of data points.
- New time weighted calculation option
Value+
- New data retrieval options for calculated data (average, min, max, etc.)
- Configurable time duration for calculation
- Drastically improved initial loading time
Quick Input+
- Improved loading time
AF Table+
- New UOM Option
- Custom tooltips for column headers
Combo Chart+
- New and improved options for event frame creation
- Add multiple buttons, customize creation dialog (default values, attribute inputs)
- New option to download the chart as an image (requires an enabled toolbar)
Bug fixes
- Events Table+: Fixed "Data Error" error message which affected old attributes not used
- Event Search Criteria: Now correctly supports multiple assets separated by ;
- Map+: Assets were not showing when one of the assets had bad data
- Linear Gauge+: Fixed number formatting issue for cultures that use , as the decimal separator
- Events Table+: Group by month now properly groups by the year and month
- Combo Chart+: Tooltip was using incorrect date time format
- Asset Comparison Bar Chart+: Fixed scale positioning for multiple scales
- Navigation Menu+: Will not use PI Web API cache any more, and always load the latest configuration after every display open
- Events Table+: Fixed delay when setting the reason code
- Histogram+: Fixed the chart not updating when the data retrieval mode was changed
- Histogram+: Fixed missing values when they were exactly at the maximum limit
- Navigation Menu+: Fixed an issue with long item names in the vertical menu
- Value+: The adhoc menu will now properly show on top of other symbols
