Housekeeping Note: PI Nexus+
We are currently in early access phase for our new full-stack PI Health & Dependency Scanner app: PI Nexus+. If you are interested in receiving early access, don't hesitate to reach out!
New Symbols
Event Comparison Chart+
An advanced event comparison chart for PI Vision. Analyze your event frames using golden batch, statistics, annotations and more.
FFT+
Frequency spectrum analysis directly in PI Vision.
New Features
General
- New Label Select control that matches the original PI Vision Label Select
- New Web API Admin option: Clear the cache for the current or all users. Use this if you have updated the Asset Framework, but the changes are not yet reflected in the custom symbols.
Combo Chart
- New Rendering Engine for improved performance and loading times
- Event Frame Display: New auto coloring mode for event frames
Heatmap
- New Rendering Engine for improved performance and loading times
Box Plot
- New Series Type "Scatter (raw)"
Gantt Chart+
- New select mode for drawing a rectangle, displaying the duration of the selected area
Manual Data Entry+
- Custom Group Names for Multiple Input Mode
- Grouping now works in multiple input mode for transposed tables
Asset Comparison Bar Chart+
- Group X Axis by Attribute Value
- Custom Attribute Labels
- New option to use an attributes value for the asset name
- New attribute Display types:
- Tooltip: Hide that value from the chart, but show it in the Tooltip
- Reference: Use the value as a reference target
Time Series Table+
- New time column option: Highlight weekends
- Now supports multiple values at the exact same timestamp for the same data source
Navigation Button / Navigation Menu+
- New config option to make them asset context aware. This means it will be able to adjust its data source if the asset context of the display is changed.
AF Table+
- New config option to disable auto refresh
Map+
- New button to hide data labels
Manual Data Entry+
- Multiple Input mode now supports copy and paste, as well as importing csv files
Bug fixes
- General: Table symbols now correctly handle Daylight Savings Time
- General: Interpolated Sync time now calculates correctly in different time zones
- Tables: Multistate Badge is now fully transparent if the color is set to "hidden"
- Tables: Tab and Enter keys now move correctly to the next cell
- Manual Data Entry: New input not appearing correctly after midnight
- Manual Input Table: Range Mode edit time was not working
- Navigation Menu: Fixed an issue where settings were not saved correctly onto the attribute
- Time Series Table: Fixed navigation link to now use the correct asset
- Time Series Table: Now correctly handles milliseconds
- Event Analytics KPI: Now correctly shows 0 count instead of an error when no events are found
- Event Analytics KPI: Fixed datetime grouping
- Asset Comparison Table+: Fixed broken navigation links
- Asset Comparison Table+: Fixed table scrolling to the top on a data update
