Vision Library+ v1.53

Important Information

If you are upgrading from version 1.49.6 or below, please take a look at the changes introduced with v1.50 here, as the all symbol files are now merged into a single file.

Also, we have introduced our new feedback page for future updates and symbols, click here to add your ideas!

New Symbols

Sankey+

This update introduces an entirely new custom symbol, the Sankey Diagram. The Sankey diagram allows visualizing flows between nodes or process stages, for example like energy, fluids, or oil and gas.

New Features

Pie Chart+

• The Pie Chart control received a major overhaul, with improved graphics and display scaling, as well as some additional configuration options:
• Better control over pie chart size
• Improved Rendering when display is zoomed

Combo Chart+

• Improved the auto scale algorithm for better scaling
• New Log Scale for single scale mode
• The "separate scale" setting now aligns the chart areas exactly on top of each other
• Additional configuration options for legend (like a custom size)

Time Series Table+

• New Option to show UOM in the column header
• Configurable time column style
• Custom column styles (change background, foreground for individual columns)
• Group columns
• Change column header alignment

Quick Input+

• Multiline Input for string datatypes
• New option to show/hide the current value for string datatypes
• Additional styling options for the save button (like color, icon and text)
• New "Button" type, that will set a pre-defined value on click (with the option to do an auto-reset afterwards)

Value+

• Now supports multiline text
• Supports custom point attributes for the tooltip

Navigation Menu+

• New config option to disable the configuration pane for non-Admins
• Customize title text color
• Customize button height in horizontal mode
• Now fully supports mobile use
• Kiosk mode will now carry over to subsequent displays

WebView+

• Each page can now have its own interval time for the slideshow
• Introduced a new global reference time for the slideshow, so you can sync multiple displays/webview controls

Bug fixes

• Events Table+: Dropdown menus and hover items now use the correct style
• Manual Data Entry+: Columns cannot be resized anymore when the layout mode is not set to manual
• Linear Gauge+: Fixed scale label number formatting for very small numbers
• Time Series Table+: Fixed Joined data retrieval mode not working in some scenarios
• QuickInput+: Fixed number formatting
• QuickInput+: Fixed label not correctly showing in the tooltip
• Linear Gauge+: Fixed range bar showing black color when the hide option was used for a multistate color
