A complete PI Vision calculation function reference with practical examples for value retrieval, time expressions, comparisons, strings, math, and range-based analysis.
PI Vision calculations are display-level expressions that combine PI points, AF attributes, operators, time expressions, and functions. They are useful when a calculation belongs to one display or dashboard and needs to be evaluated with the selected time range.
Start here
How to use the PI Vision function reference
Insert a data item into the calculation editor, then use the function name and argument pattern shown below as a starting point. Replace 'tag1' with a real PI point or AF attribute and keep time expressions in straight single quotes.
TagVal('tag1','*')
TagAvg('tag1','*-1h','*')
if('tag1' > 10) then 1 else 0
When a formula is not accepted, simplify it first. Confirm the data reference works by itself, then add one function, one operator, or one time argument at a time. This makes it easier to distinguish syntax errors from data, security, or time-range problems.
Choose by outcome
PI Vision calculation functions by job
Read a value or range
TagVal, PrevVal, NextVal, TagAvg, TagMax, TagMin, TagSpan, and TagTot help retrieve or summarize PI data.
Turn conditions into results
If, Or, NotEquals, and the Find* functions help classify states or locate a condition in a time range.
Format the display result
Text, Left, Trim, and UCase are useful when a table, label, or status symbol needs a readable text result.
The lookup table
Complete PI Vision calculation function reference
The examples below preserve the established function list while adding clearer group context and copy-friendly formatting. Test each expression against the PI Vision release and data reference used in your environment.
| Function | What it does | Example usage |
|---|---|---|
| Exp | Calculates the exponential value of a number. | Exp(2) |
| False | Represents a Boolean false value. | False |
| FindEq | Finds the first occurrence of a specified value within a range. | FindEq('tag1','-1d','*',50) |
| FindGE | Finds the first occurrence of a value greater than or equal to a specified value. | FindGE('tag1','-1d','*',50) |
| FindGT | Finds the first occurrence of a value greater than a specified value. | FindGT('tag1','-1d','*',50) |
| FindLE | Finds the first occurrence of a value less than or equal to a specified value. | FindLE('tag1','-1d','*',50) |
| FindLT | Finds the first occurrence of a value less than a specified value. | FindLT('tag1','-1d','*',50) |
| FindNE | Finds the first occurrence of a value not equal to a specified value. | FindNE('tag1','-1d','*',50) |
| Hour | Extracts the hour component from a time expression. | Hour('t') |
| If | Returns one value when a condition is true and another when it is false. | if('tag1' > 10) then 0 else 1 |
| Left | Extracts a specified number of characters from the left side of a string. | Left('string',3) |
| Ln | Calculates the natural logarithm of a number. | Ln(10) |
| Max | Returns the maximum value from a list of arguments. | Max('tag1','tag2','tag3') |
| Min | Returns the minimum value from a list of arguments. | Min('tag1','tag2','tag3') |
| Minute | Extracts the minute component from a time expression. | Minute('t') |
| Month | Extracts the month component from a time expression. | Month('t') |
| NotEquals | Compares two values and returns true when the first is not equal to the second. | 'tag1' <> 'tag2' |
| NextVal | Returns the next value after a specified time. | NextVal('tag1','t') |
| Or | Performs a logical OR operation on two Boolean values. | 'tag1' or 'tag2' |
| PrevVal | Returns the previous value before a specified time. | PrevVal('tag1','t') |
| Round | Rounds a number to the nearest integer or specified number of decimal places. | Round('tag1',2) |
| Second | Extracts the second component from a time expression. | Second('t') |
| Sin | Calculates the sine of an angle in radians. | Sin(0) |
| TagAvg | Calculates the average of a tag over a specified time range. | TagAvg('tag1','-1h','*') |
| TagMax | Retrieves the maximum value of a tag within a specified time range. | TagMax('tag1','-1h','*') |
| TagMin | Retrieves the minimum value of a tag within a specified time range. | TagMin('tag1','-1h','*') |
| TagSpan | Returns the span, or difference between maximum and minimum, of a tag. | TagSpan('tag1') |
| TagSource | Retrieves the point source string of a tag. | TagSource('tag1') |
| TagTot | Calculates the totalized value, or time integral, over a specified range. | TagTot('tag1','y','*',85) |
| TagType | Retrieves the type character of a tag, such as I, R, or D. | TagType('tag1') |
| TagTypVal | Retrieves the typical value of a tag. | TagTypVal('tag1') |
| TagVal | Retrieves the archived value of a tag at a given time. | TagVal('tag1','23-aug-2012 15:00:00') |
| TagZero | Retrieves the zero value of a tag. | TagZero('tag1') |
| Tan | Calculates the tangent of an angle in radians. | Tan(1) |
| Tanh | Calculates the hyperbolic tangent of a number. | Tanh(1) |
| Text | Concatenates strings representing argument values. | Text(Round('sinusoid',1)," is the current value of 'sinusoid' at ",'*') |
| Total | Returns the sum of two or more values. | Total('tag1','tag2',TagVal('tag1','y')) |
| Trim | Trims blanks from both sides of a string. | Trim(" String ") |
| Trunc | Truncates a number or time to the next lower unit. | Trunc(28.75,10) |
| UCase | Converts a string to uppercase. | UCase("String") |
| Weekday | Extracts the day of the week from a time expression. | Weekday('*') |
| Year | Extracts the year from a time expression. | Year('*') |
| Yearday | Extracts the day of the year from a time expression. | Yearday('*') |
Function availability and exact behavior can vary with the PI Vision and PI System versions in use. If a function is not accepted by the editor, confirm it in the documentation for the target release and test it with the same data reference used by the display.
Practical formulas
Patterns worth copying into a display
Retrieve one point value
Use TagVal when the display needs a value at a defined time.
TagVal('SINUSOID','*')Summarize a range
Use a range function when the display should summarize the selected period rather than show one sample.
TagAvg('SINUSOID','*-8h','*')Create a status result
Return a consistent numeric or digital result so a symbol can map it to a state or color.
if('CDT158' > 70) then 1 else 0Build readable text
Combine Text with rounding when a table or label needs a human-readable message.
Text(Round('SINUSOID',1)," at ",'*')Choose the right layer
When should a calculation move to AF Analytics?
PI Vision calculations are convenient for display-specific logic. A centrally managed AF Analysis is usually a better fit when the result must be reused across many displays, run on a schedule, be governed with a clear owner, be historized to an output point, or remain consistent when different users open different displays.
- Keep it in PI Vision when the expression is local to one display or is being tested interactively.
- Use AF Analytics when the calculation is an operational business rule that must be shared, scheduled, monitored, or maintained centrally.
- Document the boundary so a future administrator knows whether to edit the display or the PI System configuration.
Make failures diagnosable
Troubleshoot PI Vision calculations by symptom
The editor rejects the expression
Check parentheses, commas, quotation marks, function spelling, and the placement of then and else. Use straight single quotes for data and time expressions.
The result is blank
Test the underlying point or attribute by itself. Then check the selected time range, archive coverage, substitution or security state, and whether the function returns a type the symbol can display.
The value looks wrong
Check the time context first. *, t, relative times, and absolute timestamps do not mean the same thing. Confirm the calculation uses the intended evaluation time.
The formula works only on one display
That may be the correct behavior for a display-level calculation. If several displays need the same governed result, move the logic to AF Analytics or another managed PI System layer.
Common questions
PI Vision calculation function FAQ
Are PI Vision calculation functions the same as AF Analytics functions?
They overlap in purpose but are not the same configuration surface. Validate the expression in the PI Vision editor and use AF Analytics when the result must be centrally managed or historized.
Why does a function work in one PI Vision display but not another?
The data reference, selected time range, user permissions, PI Vision version, or symbol result type may differ. Compare those inputs before changing the formula.
What is the difference between TagVal and TagAvg?
TagVal retrieves a value at a given time. TagAvg summarizes values across a specified time range.
Can a PI Vision calculation write a value back to the PI System?
A display calculation is primarily for evaluating and presenting a result. Treat writeback as a separate workflow with its own symbol, permissions, validation, and audit requirements.
Where can I find practical syntax examples?
See the companion PI Vision Calculation Syntax guide for setup, operators, time expressions, troubleshooting, and examples beyond the function lookup table.
