Convert PI Vision to PDF with Vision Report+

Convert PI Vision to PDF with Vision Report+

Vision Report+ guide

Turn PI Vision displays into repeatable PDF reports for people who need the information outside the live dashboard.

Start with the use case

Why convert a PI Vision display to PDF?

PI Vision is designed for live exploration. A PDF is useful when a team needs a fixed snapshot for a meeting, a shift handover, a review package, a printable record, or a message to someone who does not have the display open.

Vision Report+ extends the PI Vision workflow so a display can be rendered and delivered as a PDF according to the configured reporting process. The exact output depends on the display, permissions, timing, and report settings.

Live display

Explore current PI data interactively and change the time range or context.

PDF snapshot

Capture a defined view for review, printing, sharing, or a scheduled handover.

Reporting process

Generate, store, email, or print the output according to the configured workflow.

Vision Report+ PDF report generated from an AVEVA PI Vision display
A report is most useful when the captured display has a clear audience, time range, and purpose.
Reporting capabilities

Build a repeatable path from display to distribution

Reporting is more than exporting a file once. A practical workflow defines when a report is created, who receives it, where it is stored, and how the recipient uses it.

Scheduling

Generate reports at configured times for daily, weekly, shift, or review routines.

Email delivery

Send generated files to intended recipients so stakeholders can receive the result without opening the dashboard.

Archive and print

Keep report files for the configured retention process or print a fixed view for a meeting or handover.

AVEVA PI Vision display-to-PDF reporting workflow with Vision Report+
Use the PDF output as one step in a documented reporting and distribution process.
Report design

Prepare the PI Vision display for a useful PDF

A PDF cannot compensate for a confusing display. Before scheduling or sharing it, make the intended view easy to read at the captured size.

  • Define the audience: remove symbols and detail that do not support the recipient’s decision.
  • Set the time range: make the period and context obvious so the snapshot is not misinterpreted.
  • Use clear hierarchy: place the most important KPI, exception, trend, or event context where it will be noticed first.
  • Check loading behavior: confirm that all symbols, data, and images are available when the report is generated.
  • Test permissions: verify that the account generating the report can access every required display element.
Operational workflow

Make the report part of the decision cycle

Scheduled PDFs work best when someone knows what to do with them. Pair the report with a meeting, shift handover, exception review, or archive procedure. That makes the output actionable instead of creating another inbox attachment that nobody uses.

Generate

Capture the defined PI Vision display and time context.

Review

Check the output, recipients, and any exceptions in the process.

Act

Use the report to communicate, investigate, hand over, or retain the result.

Common questions

PI Vision PDF reporting FAQ

Does converting a display to PDF make it a complete audit record?

Not by itself. A PDF is a fixed output. Whether it is an appropriate record depends on the display, timestamp, retention, access controls, procedures, and quality requirements around the workflow.

Can I schedule and email reports?

Vision Report+ supports configured scheduling and delivery workflows. Test the exact recipients, authentication, display permissions, and output timing in your environment.

What should I check if a report is incomplete?

Review display permissions, data availability, symbol loading, time range, report settings, and the account used to generate the output.
