PI Vision 2023 and Vision Library+

PI Vision 2023 and Vision Library+

PI Vision 2023 introduced a new display experience and modern authentication model. Here is what the release means for existing PI Vision environments and Vision Library+ users.

PI Vision 2023Version 3.8.0.0 adds more precise layout control, updated navigation, graphical elements, and customizable symbol colors.
OpenID ConnectThe release supports a modern authentication flow alongside the PI Server 2023 platform.
Vision Library+Vision Library+ v1.34 adds Heatmap+ and PieChart+ while maintaining compatibility with the new PI Vision interface.

What changed in PI Vision 2023?

PI Vision 2023 is a web-based display editing platform focused on more consistent layout and presentation. The update makes it easier to position symbols accurately, work with geometric patterns and graphical elements, and apply color choices that match an operational dashboard.

These changes matter when teams standardize displays across production areas. More predictable sizing and positioning reduce the amount of manual adjustment required when a display is reused, extended, or viewed at a different screen size.

More control over layout

Use precise sizing and positioning to build repeatable displays rather than relying on approximate placement.

Richer visual elements

Geometric patterns and graphical elements help separate process context, status, and supporting information.

Customizable symbol colors

Adapt visual states and dashboard styling to the conventions used by your operations team.

Updated navigation

Review navigation and display access after the upgrade so users know where existing views are located.

Authentication and PI Server compatibility

PI Vision 2023 adopts modern authentication mechanisms through OpenID Connect (OIDC). This is an important architectural change for administrators planning an upgrade because authentication, identity-provider configuration, and browser access should be validated together.

The release is designed to work with AVEVA PI Server 2023. Before upgrading a production environment, confirm that the PI Vision server, PI System components, identity provider, and network policies are aligned with your organization’s authentication design.

Administrator checkpoint: test sign-in with a representative user account, then open an existing display and verify that data access still follows the expected PI System permissions. Treat authentication testing and display testing as separate checkpoints.

What happened to imported PI ProcessBook displays?

PI Vision 2023 deprecated the feature that allowed users to view imported PI ProcessBook displays. Organizations that still depend on ProcessBook content should plan a controlled migration to native PI Vision displays.

The ProcessBook-to-PI Vision Migration Toolkit can help teams move views into a format that remains editable and maintainable in PI Vision. For a practical migration workflow, see our guide to migrating ProcessBook displays to PI Vision.

Plan the transition: inventory the ProcessBook displays still used by operators, identify their critical data sources, migrate a representative sample, and validate the resulting PI Vision displays with the people who use them.

Vision Library+ compatibility in PI Vision 2023

Vision Library+ v1.34 was prepared to work with PI Vision 2023 and its updated navigation interface. The goal is a consistent experience across supported PI Vision versions while giving dashboard authors additional ways to present process data.

Capability Why it matters in a display
Heatmap+ Reveal patterns and correlations across larger data sets with a color-coded view.
PieChart+ Show proportions and contributions when a distribution is more useful than a time trend.
Existing Vision Library+ symbols Extend PI Vision displays with additional interaction and visualization options while retaining the familiar platform workflow.

Read the related Vision Library+ v1.34 release details for the symbol-level changes. When introducing new symbols, validate them in a representative display and confirm that the chosen colors remain readable in your organization’s dashboard theme.

Upgrade checklist

  1. Review the PI Vision 2023 and PI Server 2023 prerequisites for your environment.
  2. Confirm the OpenID Connect configuration and test sign-in with representative users.
  3. Identify ProcessBook displays that need to be rebuilt as native PI Vision displays.
  4. Install and validate the compatible Vision Library+ release in a non-production environment.
  5. Test display layout, symbol behavior, permissions, and navigation before the production rollout.

PI Vision 2023 is more than a visual refresh. Its authentication changes, ProcessBook transition, and display-authoring improvements should be considered together. With a short compatibility test plan and a staged migration, teams can adopt the new platform while keeping their operational displays maintainable.
